DIN 6325 Hardened Dowel Pins
DIN 1481, Heavy duty slotted spring pins, also known as straight pins, made of spring steel, black oxide, size 1.0-30mm From China Spring Pins Manufacturer.
 |
 |
Hardened Dowel Pins , DIN 6325 / ISO 8734
Material: Carbon Steel , Stainless Steel
Size: Dia. 1.2mm - Dia. 30mm
DIN 6325 Hardened Dowel Pins Specification:
| d | a approx. | z approx. |
|---|---|---|
| M1 | 0.48 | 0.15 |
| M1.5 | 0.62 | 0.23 |
| M2 | 0.78 | 0.3 |
| M2.5 | 0.95 | 0.4 |
| M3 | 1.1 | 0.45 |
| M4 | 1.4 | 0.6 |
| M5 | 1.7 | 0.75 |
| M6 | 2.1 | 0.9 |
| M8 | 2.6 | 1.2 |
| M10 | 3 | 1.5 |
| M12 | 3.8 | 1.8 |
| M14 | 3.8 | 2 |
| M16 | 4.7 | 2.5 |
| M20 | 6 | 3 |
